✅ pneumatic driven linearslide LSK
✅ cross roller guides for precise absorption of high torque loads
✅ repeat accuracy +/- 0,01mm as external stop positions
✅ 2 sizes: LSK-4 and LSK-6
❗️own guides in which the cages run reduce the installation space❗️
❗️this enables us to install / use larger rollers ❗️
❗️up to 50% higher forces compared to others in the same installation space❗️
♻️ Our active contribution to sustainability and resource efficiency.
LSK-4
-stroke length 20, 30, 45, 60, 75 or 90 mm
-lifting force 45N @ 6 bar
-recommended payload 3kg
-available in version with/without mounted shock absorbers
LSK-6
-stroke length 30, 50, 75, 100, 125, 150, 175 or 200 mm
-lifting force 76N @ 6 bar
-recommended payload 22 to 10 kg depending on stroke
-available in version with/without mounted shock absorbers
